Surface Mount PIN Photodiode
OPR5910, OPR5913, OPR5915
Features:
?
?
?
?
?
Surface mountable
High temperature operation
Circular active area (OPR5910)
Large area photodiode (OPR5913)
880 nm peak responsivity offers maximum coupling with OPTEK’s
GaAIAs LEDs (OPR5910, OPR5915)
Description:
Each OPR5910 , OPR5913 and OP5915 device is a silicon PIN photodiode enclosed in a compact polyamide chip
carrier and is designed for open air communications and ambient light detection circuits.
The custom opaque package shields the photodiodes from stray light and can withstand multiple exposures to the
most demanding soldering conditions, while the wraparound gold-plated solder pads offer exceptional storage and
wetting characteristics.
See Application Bulletin 237 for Handling Instructions.
Applications:
Ordering Information
?
?
Encoder applications
Control applications
Part
Number
OPR5910
OPR5910T
OPR5913
Receiver
Type
Photodiode
# of
Elements
1
Responsivity Reverse Voltage Active Area
(mA/mW) Min. Min. (mm 2 )
0.45 35 0.75
0.45 35 0.75
0.40 10 26.00
Packaging
Chip Tray
Tape & Reel
Chip Tray
OPR5915
Warning : Front
Window is pressure
sensitive. Do not
apply pressure or
high vacuum to
window.
OPR5913
0.45 35 7.80
OPR5910
Pin #
1
2
3
4
OPR5915
Tube
Description
Cathode
Anode
NC
NC
Pin #
1
2
3
4
Description
Anode
Cathode
Cathode
NC
Pin #
5
6
7
8
Description
NC
Cathode
Cathode
NC
Pin #
1
2
3
4
Description
Anode
Cathode
NC
NC
Pin #
7
8
9
10
Description
NC
Cathode
NC
NC
TOLERANCE IS ± .005 [0.13]
DIMENSIONS ARE IN:
[MILLIMETERS]
INCHES
5
6
Cathode
NC
11
12
Cathode
NC
OPTEK reserves the right to make changes at any time in order to improve design and to supply the best product possible.
OPTEK Technology Inc. — 1645 Wallace Drive, Carrollton, Texas 75006
Phone: (972) 323-2200 or (800) 341-4747 FAX: (972) 323-2396 sensors@optekinc.com www.optekinc.com
Issue B 03/2012
Page 1 of 2
